ISOKING TM Glass Wool Insulation Pipes
Length: 1 m.
Inner Diameter: 20-529mm.
Thickness: 30-100mm.
Density: 40-80kg/m3.
Overview of ISOKING TM Glass Wool Insulation Pipes:
ISOKING TM Glass Wool Insulation Pipe produced with our glass wool by formation through curing by applying pressure and heat after applying thermosetting cement. FIRSTFLEX TM Glass Wool Insulation Pipe is widely used for insulation of hot, cold, concealed and exposed piping operating (the highest temperature is 400°C), and in commercial buildings, residential, industrial thermal and acoustic insulation needs, industrial facilities and process, petroleum, chemical industries or power plants, which offers the most cost effective choice of insulating mechanical systems, in compliance with the top international standards (EN, DIN, ASTM).
ISOKING TM Glass Wool Insulation Pipes production lines range from 40 tons/day capacity (14, 600 tons/year).
All ISOKING TM lines comply with the latest international environmental regulations.
Distinctive Advantages of ISOKING TM Glass Wool Insulation Pipes:
Sound absorption and noise reduction; it can effectively prevent syntony.
Light materials; easy for installation.
Antisepsis, ageing resistance, anticorrosion, ensure a healthy environment.
Low moisture absorption; stable physical properties.
Low thermal conductivity: high heat preservation.
Grade A1 fireproof: incombustible permanently.
Strong resistance for extrusion and impact.
Applications of ISOKING TM Glass Wool Insulation Pipes:
Thermal insulation of steel and copper pipes used in HVAC and similar applications.
Product Specifications of ISOKING TM Glass Wool Insulation Pipes:
Dia (mm) | Thickness (mm) | ||||||||
22 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | _ | _ |
27 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | _ | _ |
34 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | _ | _ |
43 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | _ | _ |
48 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | _ | _ |
60 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | _ | _ |
76 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
89 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
114 | 25 | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
140 | _ | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
165 | _ | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
175 | _ | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
219 | _ | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
273 | _ | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
325 | _ | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
356 | _ | 30 | 40 | 50 | 60 | 70 | 80 | 100 | 120 |
377 | _ | _ | _ | _ | _ | 70 | 80 | 100 | 120 |
426 | _ | _ | _ | _ | _ | 70 | 80 | 100 | 120 |
480 | _ | _ | _ | _ | _ | 70 | 80 | 100 | 120 |
530 | _ | _ | _ | _ | _ | 70 | 80 | 100 | 120 |
630 | _ | _ | _ | _ | _ | 70 | 80 | 100 | 120 |
720 | _ | _ | _ | _ | _ | 70 | 80 | 100 | _ |
Density | 35kg/m3-80kg/m3 |
Technical Parameters of ISOKING TM Glass Wool Insulation Pipes:
Item | Unit | Index | Standard |
Density | kg/m3 | 64-96 | GB/T 13350-2000 |
Average fiber dia | µm | <8.0 | GB/T 13350-2000 |
Water content | % | <1 | GB/T 3007-1982 |
Grade of Combustibility |
| Non-combustible grade A | GB 13350-2000 |
Max. working temp | ℃ | 400 | GB/T 13350-2000 |
Thermal conductivity at 24o℃ | w/m.k | 0.32 | GB/T 10294-1988 |
Mildew resistance |
| Mildewproof | ASTM C665 |
Moisture absorption | % | <3 of weight (49oC, relative humidity 90%) | ASTM C1104 |
Sound absorption coefficient |
| 1.1 product reverberation method 96kg/m3 2000HZ | GBJ 47-83 |
Slag inclusion Content | % | <0.3 |
